Maintenance issues

2017-06-30 10:05:32

Maintenance issues


The cylinder function is to convert the compressed air pressure into mechanical energy. In normal operation, the cylinder should be with the solenoid valve power on and off the switch quickly in place. As the cylinder piston repeated movement, the cylinder wall and piston lubrication is very important. Generally through the oil mist, so that after the atomization of lubricating oil into the air flow, and with the air into the lubrication of the site, to achieve the purpose of lubrication. Work process, there is close to the oil mist cylinder lubrication effect is good, the distance cylinder lubrication effect is poor. This is particularly evident in the cylinder of the silo. The solution is to add an oil mist in the middle of the silo gas path. For the piston rod can be coated with a layer of butter to prevent corrosion. Cylinder prone to failure is leak. There are two types of leakage and leakage. Inner leakage refers to the cylinder piston components wear serious, causing the piston before and after the channeling gas, affecting the speed of the cylinder action, caused by a serious switch is not in place. Exposure refers to the piston rod and cylinder contact with the end of the seal wear serious and leakage, resulting in slow recovery of the piston rod, or even not in place.
